It can achieve continuous cyclic production, with pressing and cloth feeding operating in parallel. The production output per shift is stable and can reach the design upper limit. The cloth feeding is uniform, ensuring good consistency in the compactness and weight of each brick billet, and resulting in a low scrap rate. It is positioned as the main production equipment for small brick factories that pursue efficiency and scale.
| Model | 4-35A type brick making machine with hopper |
| Molding cycle | 35s |
| Equipped power | 4.8kw |
| Total weight | 780kg |
| Number of operators | 2-3人 |
| Overall dimensions | 1300*1180*2170mm |
| Pallet size | 850*550*30mm |
| Class production | Standard brick240*53*115mm 20000bricks Hollow brick390*190*190mm 3200bricks |
